Descriere
Series: SOLIXDisplay Size - Diagonal10.1"Display Pixel Matrix1280H x 800VSonar-StandardMEGA Side Imaging, MEGA Down Imaging, CHIRP Digital Sonar, DualBeam PLUSSonar-Coverage20°, 60°, (2) 86° & (2) 55° -10dB (Total of 180°)Sonar-Optional50 kHz, 50/Low Airmar CHIRP and SM3000CHIRP - Frequencies Supported 83/200 (75-155/130-250 kHz), 50/200 (28-75/130-250 kHz), Low (28-75 kHz), Med (75-155 kHz), High (130-250 kHz)Sonar-Frequencies Supported 50/83/200/455/800 kHz & 1.2 MHzDepth-Sonar1,152.4m (standard transducer), 3,152.4m (optional 50 kHz), 5,0.0m (optional Airmar CHIRP SM3000)CHIRP - Imaging-Frequencies Supported455 kHz (420-520 kHz), 800 kHz (790-850 kHz), MEGA 1.2 MHz (1.125-1.300 MHz)Depth-Down Imaging121.9m (455 kHz), 38.1m (MEGA & 800 kHz)Range-Side Imaging (Side-To-Side)243.8m (455 kHz), 76.2m (MEGA & 800 kHz)InterfaceTouch ScreenFeaturesBluetooth, Built In GPS, Built In Mapping, CHIRP Digital Sonar, Down Imaging, MEGA Imaging, Networking, Side Imaging, Touch ScreenMemory Card SlotDual Micro SDCompatible With360 Imaging, AIS, AutoPilot, Minn Kota i-Pilot Link, Minn Kota Talon, NMEA 2000, RadarPower Draw: 2.4 AmpsPower Input10.8-20 VDCPower Output Peak-to-Peak8000 WattsPower Output RMS1000 WattsScreen Snap Shot IncludedSonar Recording IncludedMount-Standard: GimbalMount-Standard Size: 11.81" W x 7.89" H x 4.45" DMount-Standard SizeIn-Dash Mounting KitMount-Optional Size11.81" W x 7.06" H x 1.52" DMount-Optional SizeXM 14 20 MSI TTransducer Mount Location:TransomGPS Chartplotting: IncludedGPS Receiver: InternalGPS Trackplotting: Included
